Poster LED Pro is designed for outdoor digital signage, offering high brightness and modular design for easy installation. Its tempered glass protection, IP65 waterproofing, and interactive functionality make it ideal for locations such as bus stations and airports.
| Specification | 3.07 mm | 4 mm | 5 mm | 2.97 mm | 3.91 mm | 4.81 mm |
|---|---|---|---|---|---|---|
| LED Configuration | SMD1415 | SMD1921 | SMD2727 | SMD1921 | SMD1921 | SMD1921 |
| Pixel Density | 105625 dot / m² | 62500 dot / m² | 40000 dot / m² | 112896 dot / m² | 65536 dot / m² | 43264 dot / m² |
| Module Size | 320 * 160mm | 250 * 250mm | ||||
| Display Size | 940 * 1580mm and Customized | 980 * 1730mm and Customized | ||||
| Cabinet Size | 1140 * 2230mm and Customized | 1180 * 2380mm and Customized | ||||
| Cabinet Weight | Single side, 215kg / pc; Double side, 285kg / pc | Single side, 230kg / pc; Double side, 300kg / pc | ||||
| IP Rating (Front / Back) | IP65 / IP65 | |||||
| Brightness | > 5000 cd / m² for copper, 6000 cd / m² for gold | > 5000 cd / m² for copper, 5800 cd / m² for gold | ||||
| View Angle | 120° / 120° | |||||
| Max. Power Consumption | 670 W / m² | |||||
| Avg. Power Consumption | 200 W / m² | |||||
| Refresh Frequency | >1920Hz | |||||
| Operating Environment | Outdoor | |||||
| Operating Power | AC100-240V - 50 / 60Hz | |||||
| Operating Temperature | -20°C ~ +50°C | |||||
