Outdoor LED panels deliver outstanding brightness and contrast, with up to 10,000 nits. Engineered with superior cooling technology, these panels are ideal for media displays in extreme weather, offering front and rear maintenance and robust waterproofing (IP65/IP54).
| Pixel Pitch (mm) | 2.97 | 3.91 | 4.81 | 6.67 | 8 | 10 | 10 | 16 |
|---|---|---|---|---|---|---|---|---|
| LED | SMD 3in1 | DIP 347 | ||||||
| Module Resolution | 84x84 | 64x64 | 52x52 | 48x48 | 40x40 | 32x32 | 32x32 | 20x20 |
| Module Size (WxH) | 250x250mm | 320x320mm | ||||||
| Pixel Density (pixels / m²) | 112,896 | 65,536 | 43,264 | 22,477 | 15,625 | 10,000 | 10,000 | 3,906 |
| Cabinet Resolution (WxH) | 336x336 | 256x256 | 208x208 | 144x144 | 120x120 | 96x96 | 96x96 | 48x48 |
| Cabinet Size (WxH) | 1000x1000mm | 960x960mm | ||||||
| Cabinet Weight (kg / m²) | 50 | 48 | ||||||
| Cabinet Material | Sheet metal | |||||||
| Ingress Protection | IP65 / IP54 | |||||||
| Maintenance | Front / Rear | |||||||
| Refresh Rate (Hz) | > 1920-3840 | > 3840 | ||||||
| Brightness (nits) | 5,000-8,000 | 5,000-8,500 | 5,000-8,500 | 5,500-9,500 | 6,500-10,000 | 7,000-10,000 | 8,500-10,000 | 6,000-10,000 |
| View Angle (H./V .) | 120° / 120° | 120° / 60° | ||||||
| Contrast Ratio | 4,000 : 1 | 3,000 : 1 | ||||||
| Max. Power Consumption | 600-800W / m² | 360W / m² | ||||||
| Avg. Power Consumption | 266W / m² | 120W / m² | ||||||
